MANUAL S/M UV EXPOSURE SYSTEM

MANUAL S/M UV EXPOSURE SYSTEM

SKU：UVE-M570C
Product Contact
Wendy Tseng
886-952-093-967
Product Enquiry
  1. Panel Dimension：
    Panel size：1300*650mm(25″*25″，2pcs)
  2. Dimension(W/D/H)：2100/2891/1756+110wheels(mm)
  1. Using communication mode compensated monitoring LED brightness quality
  2. Bulit-in temperature module that can monitor LED board temperature any time
  3. LED light source modular design that easy maintenance and replacement
  4. UV LED secondary optical design, small angle light design
  5. Automatic energy calibration and compensation, uniformity can automatic calibration to above 90%
  6. Through multi-wavelength mixed achieves the best resolution, L/S=50/50μm
